DK8-15 automatic concrete making machine

block plant,concrete block machine,concrete block plant The Main Features: 1.Telecommunication control system with with PLC to make great convenience in operating and monitoring in other place, fault diagnosis and system upgrade. and save labor 2.This production line is matched with color- layered material feeding for making various colors face bricks. Meanwhile, The bricks are stacked automatically by the brick stacking machine, then sent by the for truck to the maintenance house or natural maintenance 3. It can produce lots of cement-brick to satisfy different needs in the market, such as hollow block ,standard brick, interlocking bricks, roadside block, bricks for square,yard,blind and so on. Technical Data : Control system PLC controlling Pallet size 860×860×25mm Machine weight 8.5T The frequency of Vibration(hz) 50-100hz Circle time(s) 15-20s Installed capacity(kw) 28.kw Production capacity: Specification of production Number of blocks per pallet Pecs/h Pcs/8hs Pcs/300days Hollow Block 390×190×190 8 1,920 15,360 9,216,000 Multicultural Bricks 240×115×90 18 4,320 34,560 20,736,000 Standard Bricks 240×115×53 39 9,360 74,850 44,928,000 Paving bricks 200×100×60 28 6,720 53,760 32,256,000
